Addressable Fire Detection

OnePanels

World-First En54 approved fully-touchscreen fire panel!
Stylish, clean, innovative, minimalist product range designed in Milano.

OneDetectors

World First En54 part 29 approved multi-criteria addressable detector with dual optical technology. Built to reduce false Alarm. Customizable to match with the building interior décor.

Icon - TeledataOne

OneModules

All Teledata modules are multi-modules which help save time and money.


Icon - TeledataOne

Loop devices

Aesthetically pleasing call point with secondary glass protection to avoid unwanted alarms. Sirens Certified En54-3 and En54-23

Addressable Fire devices

The TELEDATA products for the fire detection are compliant to the legislations in force EN 54/2 54/4 related to the fire detection (EN 54-2) and the power supply (EN 54-4). The TELEDATA fire detection panels are capable to manage up to 240 detectors for loop offering solutions from 1 loop up to 16 loops.

Why Teledata

Design

A stylish, clean, innovative, minimalist product range designed in Milan. First, fully touchscreen EN54 certified fire alarm panel in the world

Usability

Touchscreen: Easy to use operator menu designed for convenience even for End User



Reliability

Our current prestigious projects portfolio is a guarantee of our products and services satisfaction

Setting Icon - TeledataOne

Customization

Fully customizable product range to match your prestigious project décor

Product - TeledataOne

Design

Our goal is to design, develop and bring to market stylish and innovative products.

Usability

Our Slogan is Safety and Simplicity

Icon - TeledataOne
Customized Icon - TeledataOne

Customization

All products can be customized and styled to blend into your building. Our technology is perfect for architects and prestigious buildings

Teledata presents

A New Fire Detection System — Teledata One.

Made ​​in italy, completely touch screen and expandable up to 9 loops.

Design

A unique Italian design with a programmable side led.

Usability

Touchscreen: Easy to use operator menu designed for quicker programming learning.

Reliability

Our current prestigious international projects portfolio help you secure your important project with your customers.

Setting Icon - TeledataOne

Customization

A fully customizable product range helps you match with your end-user and architect décor.

Expandability

Up to 128 panels can be connected to a network loop. For easier management of unlimited scale fire system.

Brand Identity

Your own company logo can be implemented into the fire panel as well as branded certification, FW features, protocol,  packaging, and much more.

Teledata Solutions Wireless Fire Detection

Wireless

Completely integrated with best world class addressable wireless fire detection.

Cloud Icon - TeledataOne

Cloud

Cloud based Programming: System can be programmed from computer / laptop, and viewed remotely .

Don’t just read - TOUCH!

Today, interacting with TOUCH is part of everything around us and everything we do. Fire Alarm Control Panels should not be any different. TeledataOne is not just a user interface; it is the graphical representation of commands, functions, and important information on the Fire Alarm Control Panel. All the commands, information, devices, zones, are presented using simple graphical pictures, which increases the ease of use. Additional peace-ofmind comes through the panel’s three levels of user passwords. These ensure that only qualified people can access to the right information they need

Language Friendly Innovation

With TeledataOne the user has a huge number languages to choose from, even the most difficult characters displayed on the advanced touch panel. Easy of communication is the main mission of TeledataOne research and development team, making communication with the user much a simpler task.

Advanced Architecture, means low-cost installations

Each loop connected to the TeledataOne panel can accommodate up to 240 devices in any combination. The panel utilizes the robust TeledataOne protocol that can extend up to 3500m using 1.5mm² fire-rated cables**. Each loop can support all devices with isolators allowing ease of finding fault and protecting the other devices in case of a single failure.

One Cloud New Era Of Commissioning

With ONE CLOUD, the commissioning now is more innovative. The panel has different modes of programming capability, such as USB import, and direct programming from the touch screen; TeledataOne innovated OneCloud based programming, allowing the engineer to program the panel over the cloud saving time and visits to site. Finally, the programming being saved on the OneCloud platform can be shared and modified by more specialized personnel for instant remote support anywhere in the world

Flushed Frame

The TeledaOne panel allows flushed mount installations making the already good looking panel more aesthetically pleasing.

New Era of Fire Alarm Detection

TeledataOne is marking a new era of innovation in fire detection and alarm system technology. System surpasses the performance of any addressable panels in the market. Based on state of the art 32-bit microprocessor technology, the TeledataOne can communicate swiftly over a 5Km loop length, fully loaded with 240 loop devices. The TOUCH user interface enhances the user’s experience by making navigation through menus, programming and response times swifter, easier and more effective

Easy to program

The TeledataOne addresses all the devices electronically. No dip-switches, or rotary switches, or bar-code scanning is required. This feature not only makes the programming faster and easier, it also can provide a safe-addressing topology to the devices on the loop. All sounder tones, flasher speeds, day and night sensitivity settings, holiday setting, automatic commissioning test, unlimited time delays, alarm duration, pre-alarm commissioning, double knock events, special event linked programs, to name few of this powerful commissioning capability.

Maintenance is now easy

Effective maintenance, is in fact, the most important function of after sales service that Teledata strives to provide to its clients. Now detector alerts appear in a graphical, colourful presentation rather than written format. A White detector means clean; Green means some dirt is identified, Yellow means an increased the level of dirt, and finally Red means replace the detector. While the Teledata detectors are already equipped with drift compensation and patented double dust trap; easy to identify maintenance support is the key feature of TeledataOne. In addition, all the other main functions such as disabled devices will appear in the much easier to understand graphical presentation. Finally, over 850 events storage, will make the panel ready to accommodate a lengthy history of events for the user to scroll between.

Custom Colors

Custom Colors Teledata One
Teledata One Detector Standing
Design Milano

Invisible Design

Created with architect for zero design impact in prestigious buildings installation

Black Detector Teledata One

Benefits

  • Dual Optical technology – Reduce false alarms without losing response to real fires
  • Approved En54-29 ( certification pending)
  • Lower Profile
  • Unique Address ID on each detector allow for Auto-addressing even with loop cabled with ‘T” connection
  • Better insect and dust immunity chamber
  • Latest sensor and chip in the industry for better performance
  • Unique Address ID on each detector enable Loop mapping which identifies the exact position of the detector in the loop
  • Onboard programmable output to add base sounder

Additional Benefits

  • Easy to fit the base and easy to mount which saves time
  • Isolator in the head for better loop protection
  • Addressed electronically. No dip-switches, or rotary switches
  • Detector Log saved on each detector for quality monitoring
  • 240 devices per loop can communicate swiftly over a 5km loop length
One Detector Black Teledata One

When You Choose Teledata You Chose Life Safety & Security System Designed and Made in Italy
